LNMR 501432-CB LC228E
Product data
chip breaker Description of chip breaker (z.B.: MP= medium application steel , RKH= roughing application cast ironHFC, FMP= Fine and medium application steel,...) | CB |
grade Description of cutting grade (f.e. BCP25M, BCK20M, BCP20T, etc.). | LC228E |
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 2 |
name of tool system Description of the tool system. | Drehen-ISO |
| corner angles [EPSR] | 90 |
| length of cutting edge [L] | 50.8 |
| inner circle [IC] | 0 |
| cutting edge height [S] | 14 |
| corner radius [RE] | 3.2 |
insert execution r/n/l [IH] AExecution of indexable insert running direction R= Indexable insert right hand cutting L= Indexable insert left hand cutting N= for both cutting directions | N |
| insert height [S1] | 14 |
cutting material [GRADE] Description of grade(f.e.BCP25M, BCK20M, BCP20T, etc.). | LC228E |
coating [COATN] Description of coating. | CVD |
Norm [NSM] Indicates the standard to which the product belongs. | DIN-4000-76 |
coating coating type CVD or PVD. | Nanolock schwarz |
insert size The size of the plate is specified in millimetres. | LNMR 5014 |
edges/ insert Number of usable cutting edges per indexable insert. | 2 |
insert shape The insert-type describes the shape of the insert. | LNMR |
2D Drawing
