Ordernumber
5071202
Internal thread holder
Right-hand clamp holder for internal machining with screw clamping and coolant hole, for indexable insert form “U” and indexable insert size: 22
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 25 |
| cutting direction [HAND] | R |
| borehole diameter [DCD] | 32 |
| total length [OAL] | 250 |
| functional range [WF] | 16 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
2D Drawing
