BF90 AP10.063 Z08
Ordernumber
5079221
Face milling cutter ISO 90P
Face milling cutter made of steel for holding indexable inserts from the ISO 90P system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ISO 90P |
| connection diameter machine [DCONMS] | 22 |
| cutting direction [HAND] | R |
| tool execution [BMC] | S |
| cutting diamter [DC] | 63 |
| total length [OAL] | 40 |
ramping angle max [RMPX] Maximum ramping angle of milling cutter. | 0.7 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 8 |
| depth of cut max. [APMX] | 9 |
| hub diameter [DHUB] | 46 |
cutter type A distinction is made between the following milling cutter types:
| Aufsteckfräser |
2D Drawing
Contact
Do you have any questions?
Suitable products
Milling
APKT 100304 SR-MP2 BCP35M
Ordernumber
5085190
APKT 100304 SR-MM2 BCM40M
Ordernumber
5085158
APKT 100304 SR-RK2 BCK20M
Ordernumber
5085202
APKT 100304 SR-RP2 BCP30M
Ordernumber
5092141
APKT 100304 SR-RK2 BCK15M
Ordernumber
5092144
APKT 100304 SR-MP2 BCP25M
Ordernumber
5085192
APKT 100304 SR-RP2 BCP35M
Ordernumber
5085194
APKT 100304 SR-RP2 BCP40M
Ordernumber
5092143
APHT 100304 FR-MN2 BWN10M
Ordernumber
5092159
APHT 100304 FR-MN2 BCN10M
Ordernumber
5092158
