BS90 AP10.032 Z05 M16

Ordernumber

5079231

Screw on type ISO 90P

Steel base body with M16 connection thread for holding indexable inserts from the ISO 90P system in system size 10.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	ISO 90P
connection diameter machine [DCONMS]	16
shank length [LS]	24
cutting direction [HAND]	R
cutting diamter [DC]	32
total length [OAL]	67
head length [LH]	43
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	5
number of edges usable, face side [ZEFF] number of edges usable, face side.	5
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Einschraubfräser
