BE90 AP16.040 Z04

Ordernumber

5079242

End milling cutter ISO 90P

Steel base body with shaft and weld-on clamping surface for holding indexable inserts from the ISO 90P system in system size 16.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	ISO 90P
connection diameter machine [DCONMS]	32
shank length [LS]	60
cutting direction [HAND]	R
cutting diamter [DC]	40
total length [OAL]	115
head length [LH]	55
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	4
number of edges usable, face side [ZEFF] number of edges usable, face side.	4
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Schaftfräser
