BF45 ON08.080 Z07

Ordernumber

5081742

Face milling cutter PItec 45N

Face milling cutter made of steel for holding indexable inserts from the PItec 45N system in system size 08.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	PItec 45N
connection diameter machine [DCONMS]	32
cutting direction [HAND]	R
tool execution [BMC]	S
cutting diamter [DC]	80
total length [OAL]	50
number of edges usable, face side [ZEFF] number of edges usable, face side.	7
cutting diamter 2 [DC2]	90
depth of cut max. [APMX]	5
hub diameter [DHUB]	78
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Aufsteckfräser
