BF90 LN13.063 Z04

Ordernumber

5083664

Face milling cutter DELTAtec 90N tang

Face milling cutter made of steel for holding tangentially clamped 90° indexable inserts from the DELTAtec 90N tang system in system size 13.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	DELTAtec 90N Tang
connection diameter machine [DCONMS]	22
cutting direction [HAND]	R
tool execution [BMC]	S
cutting diamter [DC]	63
total length [OAL]	40
number of edges usable, face side [ZEFF] number of edges usable, face side.	4
depth of cut max. [APMX]	12
hub diameter [DHUB]	48
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Aufsteckfräser
