BF88 SN12.100 Z11
Ordernumber
5085876
Face milling cutter THETAtec 88N
Face milling cutter made of steel for holding indexable inserts from the THETAtec 88N system in system size 12.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | THETAtec 88N |
| connection diameter machine [DCONMS] | 32 |
| cutting direction [HAND] | R |
| tool execution [BMC] | S |
| cutting diamter [DC] | 100 |
| total length [OAL] | 50 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 11 |
| depth of cut max. [APMX] | 10 |
| hub diameter [DHUB] | 80 |
cutter type A distinction is made between the following milling cutter types:
| Aufsteckfräser |
2D Drawing
