BF90 LN10.040 Z05
Ordernumber
5085886
Face milling cutter DELTAtec 90N
Face milling cutter made of steel for holding 90° indexable inserts from the DELTAtec 90N system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | DELTAtec 90N |
| connection diameter machine [DCONMS] | 16 |
| cutting direction [HAND] | R |
| tool execution [BMC] | S |
| cutting diamter [DC] | 40 |
| total length [OAL] | 40 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 5 |
| depth of cut max. [APMX] | 9 |
| hub diameter [DHUB] | 35 |
cutter type A distinction is made between the following milling cutter types:
| Aufsteckfräser |
2D Drawing
