BE90 LN10.032 Z03
Ordernumber
5085891
End milling cutter DELTAtec 90N
Steel base body with shaft and weld-on clamping surface for holding 90° indexable inserts from the DELTAtec 90N system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | DELTAtec 90N |
| connection diameter machine [DCONMS] | 32 |
| shank length [LS] | 83 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 32 |
| total length [OAL] | 125 |
| head length [LH] | 42 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 3 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 3 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
