BF90 LN13.250 Z16 NC

Cutting Milling Edge milling DELTAtec 90N tang

Ordernumber

5093005

Face milling cutter DELTAtec 90N tang

Face milling cutter made of steel without IC for holding tangentially clamped 90° indexable inserts from the DELTAtec 90N tang system in system size 13.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	DELTAtec 90N Tang
connection diameter machine [DCONMS]	60
cutting direction [HAND]	R
tool execution [BMC]	S
cutting diamter [DC]	250
total length [OAL]	75
number of edges usable, face side [ZEFF] number of edges usable, face side.	16
depth of cut max. [APMX]	12
hub diameter [DHUB]	190
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Aufsteckfräser
