BFH90 AP10.050 Z05 046
Ordernumber
5108642
Face milling cutter ISO 90P
Face milling cutter in helical porcupine cutter execution made of steel for holding indexable inserts from the ISO 90P system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ISO 90P |
| connection diameter machine [DCONMS] | 22 |
| cutting direction [HAND] | R |
| tool execution [BMC] | S |
| cutting diamter [DC] | 50 |
| total length [OAL] | 60 |
ramping angle max [RMPX] Maximum ramping angle of milling cutter. | 0.9 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 46 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 5 |
| depth of cut max. [APMX] | 46 |
| hub diameter [DHUB] | 48 |
cutter type A distinction is made between the following milling cutter types:
| Aufsteckfräser |
2D Drawing
