A0810H-SDUCR 07
Ordernumber
5111990
Internal turning tool holder
Right-hand tool holder with screw clamping, for indexable insert types:
DC.. 0702..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 10 |
| cutting direction [HAND] | R |
| borehole diameter [DCD] | 12.5 |
| total length [OAL] | 100 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 93 |
| cutting edge length [L] | 7 |
| functional range [WF] | 5 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
tool holder type The tool holder type is described by the standard designation. | SDUCR |
2D Drawing
