BF00 RD16.100 Z07
Ordernumber
5116885
Face milling cutter ISO 00P
Face milling cutter made of steel for holding indexable inserts from the ISO 00P system in system size 16.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ISO 00P |
| connection diameter machine [DCONMS] | 32 |
| cutting direction [HAND] | R |
| tool execution [BMC] | S |
| cutting diamter [DC] | 100 |
| total length [OAL] | 52 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 7 |
| depth of cut max. [APMX] | 8 |
| hub diameter [DHUB] | 75 |
cutter type A distinction is made between the following milling cutter types:
| Aufsteckfräser |
2D Drawing
