BS00 BE10.010 Z02 M6
Ordernumber
5117345
Screw on type BALLtec
Multifunctional steel base body with M6 connection thread for holding indexable inserts from the BALLtec/TORROtec system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | BALLtec |
| connection diameter machine [DCONMS] | 6 |
| shank length [LS] | 13.5 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 10 |
| total length [OAL] | 36.5 |
| head length [LH] | 23 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 2 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 2 |
cutter type A distinction is made between the following milling cutter types:
| Einschraubfräser |
2D Drawing
