BS00 BE16.016 Z02 M8

Ordernumber

5117349

Screw on type BALLtec

Multifunctional steel base body with M8 connection thread for holding indexable inserts from the BALLtec/TORROtec system in system size 16.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	BALLtec
connection diameter machine [DCONMS]	8
shank length [LS]	16
cutting direction [HAND]	R
cutting diamter [DC]	16
total length [OAL]	44
head length [LH]	28
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	2
number of edges usable, face side [ZEFF] number of edges usable, face side.	2
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Einschraubfräser
