BS00 BE32.032 Z02 M16

Ordernumber

5117373

Screw on type BALLtec

Steel base body with M16 connection thread for holding indexable inserts from the BALLtec system in system size 32.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	BALLtec
connection diameter machine [DCONMS]	16
shank length [LS]	22
cutting direction [HAND]	R
cutting diamter [DC]	32
total length [OAL]	65
head length [LH]	43
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	2
number of edges usable, face side [ZEFF] number of edges usable, face side.	2
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Einschraubfräser
