BEU90 AP10.0750 Z03
Ordernumber
5132834
End milling cutter ISO 90P
Steel base body with shaft and weld-on clamping surface for holding indexable inserts from the ISO 90P system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ISO 90P inch |
| connection diameter machine [DCONMS] | 0.75 |
| shank length [LS] | 1.875 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 0.75 |
| total length [OAL] | 3.375 |
| head length [LH] | 1.5 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 3 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 3 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
Contact
Do you have any questions?
Suitable products
Milling
APKT 100304 SR-MP2 BCP35M
Ordernumber
5085190
APKT 100304 SR-MM2 BCM40M
Ordernumber
5085158
APKT 100304 SR-RK2 BCK20M
Ordernumber
5085202
APKT 100304 SR-RP2 BCP30M
Ordernumber
5092141
APKT 100304 SR-RK2 BCK15M
Ordernumber
5092144
APKT 100304 SR-MP2 BCP25M
Ordernumber
5085192
APKT 100304 SR-RP2 BCP35M
Ordernumber
5085194
APKT 100304 SR-RP2 BCP40M
Ordernumber
5092143
APHT 100304 FR-MN2 BWN10M
Ordernumber
5092159
APHT 100304 FR-MN2 BCN10M
Ordernumber
5092158
