BFU90 AP16.5000 Z09

Ordernumber

5132846

Face milling cutter ISO 90P

Face milling cutter made of steel for holding indexable inserts from the ISO 90P system in system size 16.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	ISO 90P inch
cutting direction [HAND]	R
tool execution [BMC]	S
cutting diamter [DC]	5
number of edges usable, face side [ZEFF] number of edges usable, face side.	9
hub diameter [DHUB]	3.75
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Aufsteckfräser
