BS90 TE10.010 Z02 M6
Ordernumber
5136372
Screw on type TORROtec
Steel base body with M6 connection thread for holding indexable inserts from the TORROtec system in system size 10.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | TORROtec |
| connection diameter machine [DCONMS] | 6 |
| shank length [LS] | 13.5 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 10 |
| total length [OAL] | 36.5 |
| head length [LH] | 23 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 2 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 2 |
cutter type A distinction is made between the following milling cutter types:
| Einschraubfräser |
2D Drawing
