BS00 BE08.008 Z02 077 M4.5

Ordernumber

5136986

Screw on type BALLtec

Multifunctional steel base body with M4.5 connection thread for holding indexable inserts from the BALLtec/TORROtec system in system size 08.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	BALLtec
connection diameter machine [DCONMS]	4.5
shank length [LS]	13
cutting direction [HAND]	R
cutting diamter [DC]	8
total length [OAL]	36
head length [LH]	23
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	2
number of edges usable, face side [ZEFF] number of edges usable, face side.	2
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Einschraubfräser
