BS90 SD06.025 Z04 M12
Ordernumber
5142947
Screw on type DELTAtec 90P feed
Steel base body with M12 connection thread for holding HFC indexable inserts from the DELTAtec 90P feed system in system size 06.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | DELTAtec 90P Feed |
| connection diameter machine [DCONMS] | 12 |
| shank length [LS] | 22 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 25 |
| total length [OAL] | 54 |
| head length [LH] | 32 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 4 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 4 |
cutter type A distinction is made between the following milling cutter types:
| Einschraubfräser |
2D Drawing
Usage
