CEB90 TE16.016 Z02 175

Cutting Milling 3D Milling TORROtec

Ordernumber

5149520

End milling cutter TORROtec

Base body made of solid carbide with soldered steel shaft, smooth shaft, cylindrical functional length and IC, for holding indexable inserts from the BALLtec/TORROtec system in system size 16.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	TORROtec
connection diameter machine [DCONMS]	16
shank length [LS]	120
cutting direction [HAND]	R
cutting diamter [DC]	16
total length [OAL]	175
head length [LH]	55
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	2
number of edges usable, face side [ZEFF] number of edges usable, face side.	2
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Schaftfräser

2D Drawing
