CEB90 TE25.025 Z02 210
Ordernumber
5149525
End milling cutter TORROtec
Base body made of solid carbide with soldered steel shaft, smooth shaft, cylindrical functional length and IC, for holding indexable inserts from the BALLtec/TORROtec system in system size 25.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | TORROtec |
| connection diameter machine [DCONMS] | 25 |
| shank length [LS] | 120 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 25 |
| total length [OAL] | 210 |
| head length [LH] | 90 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 2 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 2 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
