BE30 TC16.006 Z02 100
Ordernumber
5161427
End milling cutter ISO chamfer
Steel base body with shaft and weld-on clamping surface for holding indexable inserts from the ISO chamfer system in system size 11.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | Fasfräser |
| shank length [LS] | 62 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 6 |
| total length [OAL] | 100 |
| head length [LH] | 38 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 2 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 2 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
