UC10.016.066 SH Z4 HA

CuttingMillingSolid carbide millingUNItecChamfering
Ordernumber
5162912
Solid carbide milling Chamfering
Solid carbide milling tool from the UNItec line in a short execution, with a balanced price/performance ratio for chamfering and deburring of components for all common steel, cast iron and stainless materials.

Product data

grade

Description of cutting grade (f.e. BCP25M, BCK20M, BCP20T, etc.).

VHM PVD
delivery quantiy min

The minimum delivery quantity must be fulfilled for an order.

15
name of tool system

Description of the tool system.

UNItec
P1 main

P – Steel, P1
Material classification:

1.0037 (S25GT)
1.0503 (C45)
1.0718 (11SMnPb30)
1.1158 (C25E)
1.1191 (C45E)
1.1203 (C55E)
1.1274 (C101E, C100S)

220 - 265
P2 main

P – Steel, P2
Material classification:

1.2312 (40CrMnNiMoS8-6-4)
1.2714 (55NiCrMoV7)
1.3505 (100Cr6)
1.6587 (17CrNiMo6, 18CrNiMo7-6)
1.7225 (42CrMo4)
1.7361 (32CrMo12)
1.7715 (14MoV6-3)
1.8523 (39CrMoV13-9)

170 - 245
P3 main

P – Steel, P3
Material classification:

1.2085 (X33CrS16)
1.2343 (X38CrMoV5-1)
1.2379 (X153CrMoV12)
1.2581 (X30WCrV9-3)
1.2601 (X165CrMoV12)
1.3243 (HS6-5-2-5)
1.3343 (HS6-5-2)
1.7701 (51CrMoV4)

135 - 160
P5 main

P – Steel, P5
Material classification:

1.1120 (GS-20Mn5)
1.5419 (GS-22Mo4)
1.6571 (GS-34CrNiMo6)
1.6750 (GS-20NiCrMo3-7)
1.7231 (G42CrMo4)
1.7379 (GS-18CrMo9-10)

110 - 165
K2 main

K – Cast iron materials, K2
Material classification:

0.7040 (GGG-40)
0.7050 (GGG-50)
0.7060 (GGG-60)
0.7070 (GGG-70)
5.3400 (EN-GJS-800-10)
5.3403 (EN-GJS-1050-6)
5.3404 (EN-GJS-1200-3)

120 - 265
N2 main

N – Non ferrous materials, N2
Material classification:

3.2134 (G-AlSi5Cu1Mg)
3.2373 (G-AlSi9Mg)
3.2383 (G-AlSi10MgCu)
3.2581 (G-AlSi12)
3.3261 (G-AlMg5Si)
3.3525 (AlMg2Mn0.3)
3.3545 (AlMg4Mn)
3.4345 (AlZnMgCu0.5)

390 - 675
coating [COATN]

Description of coating.

PVD
connection diameter machine [DCONMS]10
shank length [LS]50
cutting direction [HAND]R
tool execution [BMC]H
cutting diamter [DC]10
cutting edge length max. [APMX]16
total length [OAL]66
number of edges usable, circumference [ZEFP]

Number of edges usable, circumference.

4
number of edges usable, face side [ZEFF]

number of edges usable, face side.

4
twist direction [FHH]R
M1 secondary

M – Stainless steel, M1
Material classification:

1.4301 (X5CrNi18-10+F3:F21A3F3: F23F3:F24A3F3:F23F3:FF3:F24)
1.4305 (X8CrNiS18-9)
1.4401 (X5CrNiMo17-12-2, X4CrNiMo17-12-2, X5CrNiMo18-10)
1.4404 (X3CrNiMo17-12-2)
1.4541 (X6CrNiTi18-10)
1.4571 (X6CrNiMoTi17-12-2)
1.4841 (X15CrNiSi25-20)
1.4958 (X5NiCrAlTi31-20)

75 - 80
M2 secondary

M – Stainless steel, M2
Material classification:

1.4362 (X2CrNiN23-4 (Ally 2304))
1.4462 (X2CrNiMoN22-5-3)
1.4501 (X2CrNiMoCuWN25-7-4)
1.4871 (X53CrMnNiN21-9)
1.4310 (X9CrNi18-8, X10CrNi18-8)

70 - 75
N3 secondary

N – Non ferrous materials, N3
Material classification:

2.0060 (E-Cu57)
2.0240 (CuZn15)
2.0360 (CuZn40)
2.0550 (CuZn40Al2)
2.0855 (CuNi2Si)
2.0978 (CuAl11Ni6Fe6)
2.1086 (G-CuSn10Zn)
2.1188 (CuSn5Pb20-C)

290 - 485

2D Drawing

2D Drawing
