UPN20.032.104 Cx Z3 HB

Cutting Milling Solid carbide milling UNItec Pro Finishing Pro

Ordernumber

5163225

Solid carbide milling general machining

Solid carbide milling tool of the UNItec Pro line in a long execution with neck. Smooth running thanks to unequal pitch and Z3 for more performance and higher cutting rates in common milling applications in non-ferrous metals. Very smooth cutting behaviour thanks to special micro-geometry and drag-ground cutting edge as well as polished flutes.

Product data

grade Description of cutting grade (f.e. BCP25M, BCK20M, BCP20T, etc.).	VHM PVD
delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	UNItec
N1 main N – Non ferrous materials, N1 Material classification: 3.0205 (Al99) 3.0305 (Al99.9) 3.0505 (AlMn0.5Mg0.5) 3.0915 (AlFeSi) 3.1255 (AlCuSiMn) 3.1325 (AlCuMg1) 3.1645 (AlCuMgPb) 3.1734 (AlCu4Mg1.5Ni2)	755 - 2 255
N2 main N – Non ferrous materials, N2 Material classification: 3.2134 (G-AlSi5Cu1Mg) 3.2373 (G-AlSi9Mg) 3.2383 (G-AlSi10MgCu) 3.2581 (G-AlSi12) 3.3261 (G-AlMg5Si) 3.3525 (AlMg2Mn0.3) 3.3545 (AlMg4Mn) 3.4345 (AlZnMgCu0.5)	290 - 1 500
N3 main N – Non ferrous materials, N3 Material classification: 2.0060 (E-Cu57) 2.0240 (CuZn15) 2.0360 (CuZn40) 2.0550 (CuZn40Al2) 2.0855 (CuNi2Si) 2.0978 (CuAl11Ni6Fe6) 2.1086 (G-CuSn10Zn) 2.1188 (CuSn5Pb20-C)	215 - 1 080
coating [COATN] Description of coating.	PVD
connection diameter machine [DCONMS]	20
shank length [LS]	72
cutting direction [HAND]	R
tool execution [BMC]	H
cutting diamter [DC]	20
cutting edge length max. [APMX]	32
total length [OAL]	104
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	3
number of edges usable, face side [ZEFF] number of edges usable, face side.	3
twist direction [FHH]	R

2D Drawing
