UPH16.036.092 FR4.0 Z4 HB

CuttingMillingSolid carbide millingUNItec ProGeneral machining Pro
Ordernumber
5163507
Solide carbide milling Mould&Die
Solid carbide milling tool of the UNItec Pro line in a long execution with neck. Mould radius for precise corner radii and Z4 for more performance and higher cutting rates in common milling in general machining. For all hardened materials up to max. 65HRC.

Product data

grade

Description of cutting grade (f.e. BCP25M, BCK20M, BCP20T, etc.).

VHM PVD
delivery quantiy min

The minimum delivery quantity must be fulfilled for an order.

5
name of tool system

Description of the tool system.

UNItec
H1 main

H – Hardened materials, hardened cast iron, H1
Material classification:

1.2343 52HRC (X38CrMoV5-1)
1.2767 54HRC (45NiCrMo16)

80 - 130
H2 main

H – Hardened materials, hardened cast iron, H2
Material classification:

1.2714 60HRC (55NiCrMoV7)
1.2842 58HRC (90MnCrV8)

60 - 90
coating [COATN]

Description of coating.

PVD
connection diameter machine [DCONMS]16
shank length [LS]56
cutting direction [HAND]R
tool execution [BMC]H
cutting diamter [DC]16
cutting edge length max. [APMX]36
total length [OAL]92
number of edges usable, circumference [ZEFP]

Number of edges usable, circumference.

4
number of edges usable, face side [ZEFF]

number of edges usable, face side.

4
twist direction [FHH]R
P1 secondary160 - 220
P2 secondary

P – Steel, P2
Material classification:

1.2312 (40CrMnNiMoS8-6-4)
1.2714 (55NiCrMoV7)
1.3505 (100Cr6)
1.6587 (17CrNiMo6, 18CrNiMo7-6)
1.7225 (42CrMo4)
1.7361 (32CrMo12)
1.7715 (14MoV6-3)
1.8523 (39CrMoV13-9)

150 - 200
P3 secondary

P – Steel, P3
Material classification:

1.2085 (X33CrS16)
1.2343 (X38CrMoV5-1)
1.2379 (X153CrMoV12)
1.2581 (X30WCrV9-3)
1.2601 (X165CrMoV12)
1.3243 (HS6-5-2-5)
1.3343 (HS6-5-2)
1.7701 (51CrMoV4)

130 - 200
P4 secondary

P – Steel, P4
Material classification:

1.4006 (X12Cr13, X10Cr13)
1.4034 (X46Cr13)
1.4057 (X19CrNi17-2)
1.4510 (X3CrTi17)
1.4542 (X5CrNiCuNb16-4)
1.4747 (X80CrNiSi20)

130 - 160
P5 secondary

P – Steel, P5
Material classification:

1.1120 (GS-20Mn5)
1.5419 (GS-22Mo4)
1.6571 (GS-34CrNiMo6)
1.6750 (GS-20NiCrMo3-7)
1.7231 (G42CrMo4)
1.7379 (GS-18CrMo9-10)

140 - 160

2D Drawing

2D Drawing
