A32S-PDUNL 11
Ordernumber
6401558
Internal turning tool holder
Left-hand tool holder with toggle lever clamping, for indexable insert types:
DN.. 1104..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 32 |
| cutting direction [HAND] | L |
| borehole diameter [DCD] | 40 |
| total length [OAL] | 250 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 93 |
| cutting edge length [L] | 11 |
| functional range [WF] | 16 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
tool holder type The tool holder type is described by the standard designation. | PDUNL |
2D Drawing
