PTGNR 1616H16
Ordernumber
6406376
External turning tool holder
Right-hand tool holder with toggle lever clamping, for indexable insert types:
TN.. 1604..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| cutting direction [HAND] | R |
| total length [OAL] | 100 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 90 |
| cutting edge length [L] | 16 |
| functional range [WF] | 16 |
| function height [HF] | 16 |
| shank width [B] | 16 |
application type The application type indicates whether the tool is for internal or external machining | Außen |
tool holder type The tool holder type is described by the standard designation. | PTGNR |
2D Drawing
Contact
Do you have any questions?
Suitable products
Turning
TNMG 160404 ER-BC LC435D
Ordernumber
6411838
TNMG 160404 ER-BC LC240F
Ordernumber
6411837
TNMG 160404 ER-BC LCP15T
Ordernumber
5029152
TNMG 160404 ER-BC LCP25T
Ordernumber
5056014
TNMG 160408 ER-BC LC435D
Ordernumber
6410961
TNMG 160408 ER-BC LCP15T
Ordernumber
5029155
TNMG 160408 ER-BC LCP25T
Ordernumber
5056018
