S16R-SCLCL 09
Ordernumber
6407212
Internal turning tool holder
Left-hand tool holder with screw clamping, for indexable insert types:
CC.. 09T3..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 16 |
| cutting direction [HAND] | L |
| borehole diameter [DCD] | 20 |
| total length [OAL] | 200 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 95 |
| cutting edge length [L] | 9 |
| functional range [WF] | 8 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
tool holder type The tool holder type is described by the standard designation. | SCLCL |
2D Drawing
Contact
Do you have any questions?
