S74 P40R-TP16
Ordernumber
6407350
Internal turning tool holder
Right-hand tool holder with finger clamping, for indexable insert types:
TP.. 1603..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 40 |
| cutting direction [HAND] | R |
| borehole diameter [DCD] | 58 |
| total length [OAL] | 350 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 92 |
| cutting edge length [L] | 16 |
| functional range [WF] | 20 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
2D Drawing
