BE45 XE04.025 Z02
Ordernumber
5103614
End milling cutter ETAtec 45P
Multifunctional steel base body with shaft and weld-on clamping surface for holding indexable inserts from the ETAtec 45P system in system size XE04/ RE13.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ETAtec 45P |
| connection diameter machine [DCONMS] | 25 |
| shank length [LS] | 56 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 25 |
| total length [OAL] | 106 |
| head length [LH] | 50 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 2 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 2 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
