BE45 XE04.036 Z03
Ordernumber
5103623
End milling cutter ETAtec 45P
Multifunctional steel base body with shaft and weld-on clamping surface for holding indexable inserts from the ETAtec 45P system in system size XE04/ RE13.
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
name of tool system Description of the tool system. | ETAtec 45P |
| connection diameter machine [DCONMS] | 32 |
| shank length [LS] | 60 |
| cutting direction [HAND] | R |
| cutting diamter [DC] | 36 |
| total length [OAL] | 124 |
| head length [LH] | 64 |
number of edges usable, circumference [ZEFP] Number of edges usable, circumference. | 3 |
number of edges usable, face side [ZEFF] number of edges usable, face side. | 3 |
cutter type A distinction is made between the following milling cutter types:
| Schaftfräser |
2D Drawing
