BEA00 RD07.015 Z02 150

Ordernumber

5116867

End milling cutter ISO 00P

Steel base body with smooth shaft and tapered functional length, for holding indexable inserts from the ISO 00P system in system size 07.

Product data

delivery quantiy min The minimum delivery quantity must be fulfilled for an order.	1
name of tool system Description of the tool system.	ISO 00P
connection diameter machine [DCONMS]	20
shank length [LS]	50
cutting direction [HAND]	R
cutting diamter [DC]	15
total length [OAL]	150
head length [LH]	100
number of edges usable, circumference [ZEFP] Number of edges usable, circumference.	2
number of edges usable, face side [ZEFF] number of edges usable, face side.	2
cutter type A distinction is made between the following milling cutter types: End milling cutter Face milling cutter Screw on type	Schaftfräser
