S10K-SCLCL 06
Ordernumber
6407202
Internal turning tool holder
Left-hand tool holder with screw clamping, for indexable insert types:
CC.. 0602..
Product data
delivery quantiy min The minimum delivery quantity must be fulfilled for an order. | 1 |
| connection diameter machine [DCONMS] | 10 |
| cutting direction [HAND] | L |
| borehole diameter [DCD] | 13 |
| total length [OAL] | 125 |
setting angle [KAPR] Positioning of the indexable insert in the carrier to the workpiece axis. | 95 |
| cutting edge length [L] | 6 |
| functional range [WF] | 5 |
application type The application type indicates whether the tool is for internal or external machining | Innen |
tool holder type The tool holder type is described by the standard designation. | SCLCL |
2D Drawing
Contact
Do you have any questions?
Suitable products
Turning
CCGT 060204 ER-BC LC435D
Ordernumber
6413130
CCGT 060204 ER-BC LCP25T
Ordernumber
5055825
CCGT 060208 ER-BC LC435D
Ordernumber
6413138
CCGT 060208 ER-BC LCP25T
Ordernumber
5055827
CCMT 060202-FM BCM25T
Ordernumber
5106897
CCMT 060202-FM BCM40T
Ordernumber
5106721
CCMT 060202-FP LCP15T
Ordernumber
5049634
CCMT 060204-FM BCM25T
Ordernumber
5106898
CCMT 060202-MM LCM20T
Ordernumber
5093105
CCMT 060202-MP LCP15T
Ordernumber
5028145
CCMT 060202-MP LCP25T
Ordernumber
5055837
CCMT 060202-MM LC435D
Ordernumber
5073333
CCMT 060204-FM BCM40T
Ordernumber
5106896
CCMT 060202-MM BCM25T
Ordernumber
5090769
CCMT 060202-FP LCP25T
Ordernumber
5055836
CCMT 060204-FP LCP25T
Ordernumber
5055838
CCMT 060204-MM LC435D
Ordernumber
5064302
CCMT 060204-MM LCM20T
Ordernumber
5093106
CCMT 060204-FP LCP15T
Ordernumber
5028158
CCMT 060204-MP LCP25T
Ordernumber
5055839
CCMT 060208-FP LCP25T
Ordernumber
5055840
CCMT 060208-FP LCP15T
Ordernumber
5028138
CCMT 060208-MP LCP25T
Ordernumber
5055841
CCMT 060204-MP LCP15T
Ordernumber
5028179
CCMT 060204-MM BCM25T
Ordernumber
5090778
CCMT 060208-MP LCP15T
Ordernumber
5028059
CCGT 060204-FN BCN10T
Ordernumber
5172790
CCGT 060204-FN BWN10T
Ordernumber
5170778
CCGT 060202-BAL LW610
Ordernumber
6403002
CCGT 060202-BAL LC610T
Ordernumber
6403001
CCGT 060204-BAL LC610T
Ordernumber
6403003
CCGT 060204-BAL LW610
Ordernumber
6403004
